- 商品名称：CKEPJP80/SC, CKEPFP80/SC船用电缆
- 添加时间：2023-03-24 09:24:51
- 推荐度：
CKEPJP80/SC, CKEPFP80/SC船用电缆
组分 Components | 代号 Code | 材料/描述 Material/Description |
系列代号 Series code | CK | 船用控制电缆 Shipboard control cable |
导体 Conductor | 绞合镀锡退火铜， IEC 60228 Class 2 Stranded tinned annealed copper (STC), IEC 60228 Class 2 | |
绝缘 Insulation | E | 乙丙橡胶 EPR, IEC 60092-351 |
内护套 Inner sheath | PJ | 无卤阻燃热固性材料 Halogen-free flame retardant thermoset compound (SHF2) |
PF | 无卤阻燃热塑性材料 Halogen-free flame retardant thermoplastic compound (SHF1) | |
单芯屏蔽 Individual screen | P | 镀锡铜丝编织 Tinned copper wire braided |
铠装 Armor | 8 | 镀锡铜丝编织 Tinned copper wire braid (TCWB) |
9 | 镀锌钢丝编织 Galvanized steel wire braided (GSWB) | |
外护套 Outer sheath | 0 | 无外护套 Without outer sheath |
5 | 无卤阻燃热固性材料 Halogen-free flame retardant thermoset compound (SHF2) | |
6 | 无卤阻燃热塑性材料 Halogen-free flame retardant thermoplastic compound (SHF1) | |
外护套颜色 Outer sheath color | 黑色(如有) Black, if any | |
燃烧特性 Flammability | SC | 低烟无卤阻燃 LSHF Flame retardant, IEC60332-3-22(CAT.A) |
芯数x截面 No. of cores x sectional area | CKEPJP/SC, CKEPFP/SC | CKEPJP90/SC, CKEPFP90/SC | CKEPJP85/SC, CKEPFP86/SC CKEPJP95/SC, CKEPFP96/SC | ||||||||
外径 Over diam. mm | 约重 Approx. weight | 外径 Over diam. mm | 约重 Approx. weight | 外径 Over diam. mm | 约重 Approx. weight | ||||||
标称 Nom. | 最大 Max. | 标称 Nom. | 最大 Max. | 80系列 | 90系列 | 标称 Nom. | 最大 Max. | 85系列 | 95系列 | ||
No. x mm2 | kg/km | kg/km | kg/km | kg/km | kg/km | ||||||
2 x 0 .75 3 x 0.75 4 x 0.75 5 x 0.75 7 x 0.75 10 x 0.75 12 x 0.75 14 x 0.75 16 x 0.75 19 x 0.75 24 x 0.75 27 x 0.75 30 x 0.75 33 x 0.75 37 x 0.75 | 9.6 10.1 11.0 12.2 13.2 17.0 17.5 18.4 19.6 20.6 24.2 24.7 25.8 26.8 28.0 | 11.0 11.5 12.5 14.0 15.0 19.0 19.5 20.5 22.0 23.0 27.0 27.5 28.5 29.5 31.0 | 104 133 164 202 260 376 432 490 559 644 812 894 991 1078 1203 | 10.7 11.7 12.6 13.8 14.8 18.6 19.1 20.0 21.2 22.2 25.8 26.3 27.4 28.4 29.6 | 12.0 13.0 14.5 15.5 16.5 20.5 21.0 22.0 23.5 24.5 28.5 29.0 30.0 31.5 32.5 | 163 226 266 315 385 537 600 668 750 848 1053 1143 1254 1353 1494 | 156 215 254 303 371 520 582 649 730 827 1029 1118 1228 1325 1465 | 12.7 13.8 14.7 16.0 17.0 21.0 21.5 22.5 23.8 24.8 28.6 29.1 30.3 31.3 32.6 | 14.0 15.0 16.5 17.5 18.5 23.0 23.5 24.5 26.0 27.0 31.5 32.0 33.0 34.5 35.5 | 210 277 322 377 450 625 688 761 850 951 1181 1272 1389 1493 1640 | 203 267 310 364 436 607 670 742 829 930 1157 1246 1362 1465 1612 |
